Hologram IoT SIM datasheets

Hologram provides a number of IoT SIM specifications to meet your deployment and specific hardware needs. An overview of hardware specifications for our IoT SIMs and software specifications applicable to those SIMs can be found below. Our SIMs are available for purchase in both triple cut card and MFF2 embedded SIM (eSIM) form factors.



A global IoT SIM for every use case

Hologram's Dual-Core and Dual-Core Capable SIMs with Fallback are industrial grade eUICC SIMs available in triple cut micro/mini/nano (2FF/3FF/4FF), and embedded SIM (eSIM, MFF2 DFN8) formats.

Hologram's Global and Canada eUICC SIMs are available in standard and industrial grade for triple cut micro/mini/nano (2FF/3FF/4FF), and in standard grade embedded SIM (eSIM, MFF2 DFN8) formats.

Standard SIMs are adequate for most use cases. Industrial grade SIMs are ruggedized for extreme situations such as wide temperature operating ranges and extended life-cycle applications. For more information, see our SIM card page.



SIM card specifications

Global SIM — Triple Cut — Standard Grade


Triple cut format

  • Mini (2FF): 25mm × 15mm × 0.71 mm
  • Micro (3FF): 15mm × 12mm × 0.71 mm
  • Nano (4FF): 12.3mm × 8.8mm × 0.71 mm

Operating characteristics

  • Electrical: 1.6V, 3V, and 5V
  • Operational temperature: −25°C to +85°C
  • Memory (NVM): 340 KB
  • Radio Access Technologies: 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Global SIM — Triple Cut — Industrial Grade


Triple cut format

  • Mini (2FF): 25mm × 15mm × 0.71 mm
  • Micro (3FF): 15mm × 12mm × 0.71 mm
  • Nano (4FF): 12.3mm × 8.8mm × 0.71 mm

Operating Characteristics

  • Electrical: 1.62V to 5.5V
  • Operational temperature: −40°C to +105°C
  • Memory (NVM): 704 KB
  • Radio Access Technologies: 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Global SIM — Embedded — Standard Grade


Embedded SIM (eSIM) format

  • MFF2 (DFN8): 6 × 5 × 0.82 mm

Operating Characteristics

  • Electrical: 1.6V, 3V, and 5V
  • Operational Temperature: −25°C to +85°C
  • Memory (NVM): 340 KB
  • Radio Access Technologies: 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Canada SIM — Triple Cut — Standard Grade


Triple cut format

  • Mini (2FF): 25mm × 15mm × 0.71 mm
  • Micro (3FF): 15mm × 12mm × 0.71 mm
  • Nano (4FF): 12.3mm × 8.8mm × 0.71 mm

Operating characteristics

  • Electrical: 1.62V to 5.5V
  • Operational Temperature: −25°C to +85°C
  • Memory (NVM): 704 KB
  • Radio Access Technologies: 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Dual-Core Capable SIM — Triple Cut


Triple cut format

  • Mini (2FF): 25mm × 15mm × 0.71 mm
  • Micro (3FF): 15mm × 12mm × 0.71 mm
  • Nano (4FF): 12.3mm × 8.8mm × 0.71 mm

Operating characteristics

  • Electrical: 1.62V to 5V
  • Operational temperature: −40°C to +105°C
  • Memory (NVM): 800 KB
  • Radio Access Technologies: 5G, 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Dual-Core Capable SIM — Embedded SIM


Embedded SIM (eSIM) Format

  • MFF2 (DFN8): 6 × 5 × 0.82 mm

Operating Characteristics

  • Electrical: 1.62V to 5.5V
  • Operational Temperature: −40°C to +105°C
  • Memory (NVM): 330 KB
  • Radio Access Technologies: 5G, 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Dual-Core SIM — Triple Cut


Triple cut format

  • Mini (2FF): 25mm × 15mm × 0.71 mm
  • Micro (3FF): 15mm × 12mm × 0.71 mm
  • Nano (4FF): 12.3mm × 8.8mm × 0.71 mm

Operating characteristics

  • Electrical: 1.62V to 5V
  • Operational temperature: −40°C to +105°C
  • Memory (NVM): 800 KB
  • Radio Access Technologies: 5G, 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Dual-Core SIM — Embedded SIM


Embedded SIM (eSIM) Format

  • MFF2 (DFN8): 6 × 5 × 0.82 mm

Operating Characteristics

  • Electrical: 1.62V to 5.5V
  • Operational Temperature: −40°C to +105°C
  • Memory (NVM): 330 KB
  • Radio Access Technologies: 5G, 4G (LTE), 3G, 2G, NB-IoT, LTE-M

Download the data sheet



Looking for additional SIM types?
We have additional SIM types that are available to contracted customers. To request a datasheet or more information, please contact our sales team.
